Compact two-wire braid hydraulic hose for high-pressure lines where space is tight and a small bend radius matters. Carries petroleum- and water-based hydraulic fluids.
VR16 packs a high working pressure into a smaller outside diameter than typical spiral hose, with a tight minimum bend radius for crowded installs — a workhorse line for mobile and industrial hydraulics.
Tube
Oil-resistant synthetic rubber, for petroleum- and water-based hydraulic fluids.
Reinforcement
Two braids of high-tensile steel wire for compact, high-pressure strength.
Cover
Abrasion- and weather-resistant synthetic rubber. Smooth cover on VR16-PRO.
Mobile EquipmentAgricultural MachineryMachine ToolsIndustrial HydraulicsTight-Routing Installs
Hose Identification LabelsVR16 STANDARD · 2-WIRE BRAID · FULL BORE 1/4"–1"
Std Reel = one standard reel length per size — our minimum order is one reel. Full material spec and temperature range available on request.
The Premium Grade
Step up to VR16-PRO.
Same compact two-wire build, engineered harder: it exceeds standard EN853 2SN / SAE 100R2AT working pressure by around 30%, halves the bend radius, and adds an abrasion-resistant smooth cover — for high-load mobile and industrial systems that punish ordinary hose.
Send us your sizes and quantities — we'll come back with pricing and lead time. Hose ships by the reel (minimum one reel per size). Private-label inquiries welcome.
