VR17 holds a single 3,045 PSI working pressure from 1/4" to 1" — so you spec and stock one rating instead of a table of them. Single-wire reinforcement in the smaller sizes, two-wire in the larger.
Tube
Oil-resistant synthetic rubber, for petroleum- and water-based hydraulic fluids.
Reinforcement
High-tensile steel wire — single braid in smaller sizes, two-wire braid in larger sizes.
Cover
Abrasion- and weather-resistant synthetic rubber. Smooth cover on VR17-PRO.
General HydraulicsMobile EquipmentSimplified StockingOEM LinesRepair & Service
Hose Identification LabelsVR17 STANDARD · COMPACT · FULL BORE 1/4"–1"
Standard VR17 — Dimensional & Pressure Data
VR17 · SAE 100R17 / ISO 11237 · Constant Pressure
Size
I.D. (mm)
O.D. (mm)
Max W.P. (PSI)
Min Burst (PSI)
Min Bend R (mm)
Weight (kg/m)
Std Reel (ft)
1/4"
10.4
12.2
3,045
12,180
50
0.19
1,000
3/8"
13.6
16.2
3,045
12,180
65
0.27
655
1/2"
16.8
19.2
3,045
12,180
90
0.46
490
5/8"
21.7
23.8
3,045
12,180
100
0.57
300
3/4"
25.6
27.7
3,045
12,180
120
0.78
200
1"
33.3
36.0
3,045
12,180
150
1.35
200
Std Reel = one standard reel length per size — our minimum order is one reel. Full material spec and temperature range available on request.
The Premium Grade
Meet VR17-PRO.
A premium single-wire braid line that exceeds standard EN853 1SN / SAE 100R1AT — lightweight, with half the bend radius and an abrasion-resistant smooth cover. Built for medium- and lower-pressure mobile hydraulics: tractors, ag equipment, machine tools, and light hydraulic lines. (Note: VR17-PRO is a 1-wire premium grade, not a higher-pressure version of VR17.)
As a 1-wire braid, VR17-PRO is rated for medium/lower-pressure mobile hydraulics — working pressure steps down with size, as is standard for 1SN-class hose.
Send us your sizes and quantities — we'll come back with pricing and lead time. Hose ships by the reel (minimum one reel per size). Private-label inquiries welcome.
